Brand Name : ZENVO
Model Number : 5LHS-90
Place of Origin : CHINA
MOQ : 1 Set
Price : Negotiable
Payment Terms : T/T,L/C
Delivery Time : 20 working days
Packaging Details : Bulk
Fuel type : Biomass pellet
Combustion mode : Decompose combustion
Feeding way : Automatic feed
Thermal power : ≥1.05
Total power : 4.48
Size : 5100*1500*2570
Thermal efficiency : 83
lgnition way : Manual ignition/automatic ignition(optional)
Control mode : Automatic control/Remote control (optional)
Output hot air temperature : ≤120
5L series energy saving and environmental protection biological particle hot air stove

The working principle of 5L-90 series hot air stove:
The fuel of biomass particles,firewood and so on is sent into the stove combustion to produce heat and flue gas,the flue gas is input to the heat exchanger and then discharged after many cycles,the cold wind is output after heating through the outer wall of the exchanger to the thermal efficiency,it has the characteristics of improving heat efficiency,heating up quickly,saving energy and reducing the cost effectively.Fast heating,full combustion and less ash produced.The exhaust volume is low,and after dust removal,it meets the requirements of national environmental protection standards.
|
|
5L-90 Biomass Pellet Hot Blast Stove Automatic Feeding Images |
